224-310KW康明斯发电用发动机可靠性高：高强度合金铸造缸体、可锻铸铁(FCD) 活塞，刚性更好，降低振动和噪声，提高了发动机适应更高的爆发压力。

High reliability: intensified alloy casting cylinder and Ferrous Cast Ductile (FCD) piston provide engine a better rigidity performance and lower vibration & noise, and also make the engine adapt to higher explosion pressure.

康明斯发电站用启心理柴油国家稳定性好: 高端的柴油设定的设计，独具的STC、ESTC 等级划分设定的设计，特异的设计的连杆上端点燃室，高压变压器喷射式柴油，加以做雾化，点燃加以。

Good fuel economy: Advanced fuel control system, unique STC, ESTC step control system, specilly-designed piston topchamber and high pressure fuel injection lead to an excellent fuel consumption rate and emission performance of engine.

康明斯发电机组用发起机瞬态稳定性非常好: 很好的发起机布局构思，加上康明斯差异化的的EFC操作系统，的控制精确高，卡死期限快。

Excellent transient performance: perfect overall engine design with unique Cummins EFC system, high precision on control and quick response time.

康明斯发电量用起因素升工作电压高: 整体布局设汁紧凑型轿车.样貌布置图适度，运营市场平稳。High lift power: Integrated and compact design, reasonable layout and smooth operation.

电喷外形 QSNT. QSK19. QSK38. QSK50提供中国国非市政道路其次周期及美洲Tier2. Tier 3排卸法律规范规范。

Electric fuel injection engines (QSNT,QSK19,QSK38,QSK50) meet the Tier3 emission regulations for China non-road vehicles and Tier2 & Tier3 emission regulations of North America.

零配件能得性好， 打着机工作及维护维养方便，投资价格低。Good availbility of spare parts, smooth engine operation, convenient engine maintenance and low cost.

发动机规格Engine Specifications

最大功率条件 Power Range   224-310KW型号规格 Type   直列/六缸/四冲程/四气门  In-ine/6-Cylinder/4-Stroke/4-Valve缸径x冲程 BoreX Stroke  125X 147mm排量 Displacement   11L外观设计长宽比 Dimension  长X宽X高(LXWX H) 1360 x 833X 1068 mm净的质量 Dry Weight   940kg

224-310KW康明斯发电机组用打着机的特质：表面积小， 解压缩比低， 网格板空气中烧水，更易开启，转动车机电源模块的优先。Compact size, high compression ratio, gile heated by air, easy for start-up, the first option of mobile vehicle power supply.

推荐机型Engine Models Recommended

打着机类型	通常用功效(kW)Prime Power	预备效率kW)Standby Power
MTA11-G2	224	246
MTAA11-G3	282	310
